Tungsten Carbide Oil Thread Drill Bit Nozzle PDC Metal Wear Resisting
PDC Metal Wear Resisting Tungsten Carbide Oil Thread Drill Bit Nozzle
Tungsten Carbide Thread Nozzle, also known as the tungsten carbide nozzle, features high temperature resistance, corrosion resistance, abrasion resistance, and high precision. It maintains its properties at temperatures up to 500°C and retains significant hardness even at 1000°C.
Our premium tungsten carbide nozzles are used across multiple industries including chemical, food processing, machinery, metallurgy, and construction for applications such as pulverizing, derusting, cleaning, and atomization.
Product Specifications
Model: MJP-LJA-3212
| Parameter |
Value |
| Outer Diameter (A) |
32.00 |
| Total Length (C) |
26.30 |
| Thread (M) |
1 1/4"-12UNF-2A |
| Small Outer Diameter (D) |
26.8 |
| Length (L) |
5 |
| Endoporus (E) |
22 |
| Chamfer Angle (F*G) |
0.6*30° |
| Transition Arc (J) |
10 |
| Transition Arc (K) |
10 |
Pore Diameter (B)
| Size |
Diameter |
| 09# |
7.14 |
| 10# |
7.95 |
| 11# |
8.74 |
| 12# |
9.53 |
| 13# |
10.31 |
| 14# |
11.13 |
| 15# |
11.91 |
| 16# |
12.7 |
| 17# |
13.5 |
| 18# |
14.29 |
| 19# |
15.08 |
| 20# |
15.8 |
| 22# |
17.48 |
| 24# |
19.1 |
| 26# |
20.6 |
| 28# |
22.2 |
Model: MJP-LJA-2712
| Parameter |
Value |
| Outer Diameter (A) |
27.00 |
| Total Length (C) |
25.40 |
| Thread (M) |
1 1/16"-12UNF-2A |
| Small Outer Diameter (D) |
21.92 |
| Length (L) |
4.75 |
| Endoporus (E) |
18 |
| Chamfer Angle (F*G) |
0.67*30° |
| Transition Arc (J) |
12.7 |
| Transition Arc (K) |
5 |
Pore Diameter (B)
| Size |
Diameter |
| 09# |
7.14 |
| 10# |
7.95 |
| 11# |
8.74 |
| 12# |
9.53 |
| 13# |
10.31 |
| 14# |
11.13 |
| 15# |
11.91 |
| 16# |
12.7 |
| 17# |
13.5 |
| 18# |
14.29 |
| 19# |
15.08 |
| 20# |
15.8 |
| 22# |
17.48 |
Model: MJP-LJA-1912
| Parameter |
Value |
| Outer Diameter (A) |
19.05 |
| Total Length (C) |
23.00 |
| Thread (M) |
3/4"-12UNF-2A |
| Small Outer Diameter (D) |
16.1 |
| Length (L) |
3.6 |
| Endoporus (E) |
13 |
| Chamfer Angle (F*G) |
0.67*30° |
| Transition Arc (J) |
10 |
| Transition Arc (K) |
10 |
Pore Diameter (B)
| Size |
Diameter |
| 09# |
7.14 |
| 10# |
7.95 |
| 11# |
8.74 |
| 12# |
9.53 |
| 13# |
10.31 |
| 14# |
11.13 |
| 15# |
11.91 |
| 16# |
12.7 |
| 17# |
13.5 |
| 18# |
14.29 |
| 19# |
15.08 |
| 20# |
15.8 |
Related Products
Production Equipment
Quality Control Equipment
Product Exhibition
Company Information
Chengdu Kedel Tools is a professional manufacturer of tungsten carbide products from China. Our company specializes in research, development and production of various cemented carbide tools. With advanced equipment and a skilled technical team, we produce and sell cemented carbide products of various shapes, sizes and grades, including:
- Cemented carbide nozzles
- Cemented carbide bushings
- Cemented carbide plates
- Cemented carbide rods
- Cemented carbide rings
- Cemented carbide rotary files and burrs
- Cemented carbide end mills
- Cemented carbide circular blades and cutters
- Cemented carbide CNC inserts
- Other non-standard cemented carbide parts
Our tungsten carbide products are exported worldwide to North America, South America, Europe, South Africa and Southeast Asia, serving industries including:
- Oil and gas industry
- Coal mining
- Mechanical seal
- Aerospace
- Steel smelting
- Metal processing
- Military industry
- New energy industry
- Packaging and printing industry
- Auto parts industry
- Chemical industry
Packing & Delivery
Packing Details: PDC Drill Bit nozzles are packed using plastic foam, solid plastic boxes and cartons for secure transportation.
Frequently Asked Questions
Q: Are you trading company or manufacturer?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock, or 15-20 days if the goods need to be produced, depending on quantity.
Q: Do you provide samples? Is it free or extra?
A: Yes, we offer samples free of charge but the customer is responsible for shipping costs.
Q: What are your payment terms?
A: For orders ≤1000USD, 100% payment in advance. For orders ≥1000USD, 30% T/T deposit with balance paid before shipment.
