Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits

Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits
Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits

Large Image :  Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits

Product Details:
Place of Origin: Sichuan, China
Brand Name: Kedel
Certification: ISO9001:2015
Model Number: KDL-QBA-0001
Payment & Shipping Terms:
Minimum Order Quantity: 10 Piece/Pieces
Price: $1.00 - $15..00 / Piece
Packaging Details: foam + small box + carton Tungsten carbide cone bit tips insert flat top button
Supply Ability: 1000000 Piece/Pieces per Week provide OEM service for carbide button insert products
Contact Now

Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits

Description
Type: DRILL BIT, Drill Bit, Tungsten Carbide Buttons For Rock Drilling Tools Machine Type: Drilling Equipment
Material: Carbide, Tungsten Carbide WC+Co Processing Type: Forging
Use: Coal Mining Product Name: Tungsten Carbide Cone Bit Tips Insert Flat Top Button
Application: Petroleum, Chemical And Mechanic Idustry Surface: Finished
Size: Cusotmized Commodity Name: Flat Top Button For Cone Bit
Grade: YG8C, YK05, Etc Certificate: ISO9001:2008
Usage: Coal Mining Port: Shanghai/Shenzhen
Highlight:

flat top Cemented Carbide Buttons

,

YG8C carbide mining button

,

Cemented Carbide Buttons Coal Mining

Cone Bit Tips Insert Cemented Carbide Buttons Flat Top For Coal Mining
Tungsten carbide cone bit tips insert flat top button. Tungsten carbide alloy buttons have unique working properties, widely used in oil drilling, snow removal equipment, quarrying, mining, tunnel engineering, and civil construction.
Key Features
  • Suitable for cone bits, diamond bits, hole sinking stabilizers, etc.
  • Reduces surface wear of steel body
  • Made from 100% raw material with strict incoming inspection
  • Overpressure sintering increases densification and extends lifespan by 30%
  • Customizable according to customer requirements
Production Process
Milling → Proportioning as required → Wet grinding → Dry → Granulation → Press → Sinter → Inspection → Package
Specifications
Below are two example specifications. We accept custom inquiries with drawings.
Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 0
Model Specification ΦA L
MJB-QXA-101 1601 10.2 10.5
MJB-QXA-101 1602 11.0 12.5
MJB-QXA-101 1603 12.5 20.0
MJB-QXA-101 1604 12.8 26.0
MJB-QXA-101 1605 13.44 19.0
MJB-QXA-101 1606 15.88 9.94
MJB-QXA-101 1607 15.88 12.0
Product Showcase
Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 1
Factory and Production Equipment
Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 2 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 3 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 4 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 5 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 6 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 7
Quality Control Equipment
Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 8 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 9 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 10 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 11 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 12 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 13
Product Exhibition
Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 14 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 15 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 16 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 17 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 18 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 19 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 20 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 21 Tungsten Carbide Flat Top Buttons 10.2mm for Coal Mining Cone Bits 22
Our Manufacturing Advantages
  1. First manufacturer to produce threaded nozzles in China
  2. Technical backbone workers with over 10 years of experience
  3. Professional team and advanced equipment
  4. Commitment to professional and sincere service
Packing & Delivery
Packing Details: Mining carbide button tips are packed using plastic foam, solid plastic box and carton.
Our mining carbide button tips offer high hardness, corrosion resistance, wear resistance and good toughness. We accept non-standard customized products with pricing based on raw material, production cost and order quantity.
Frequently Asked Questions
Q: Are you a trading company or manufacturer?
A: We are the factory.
Q: How long is your delivery time?
A: Generally 5-10 days for in-stock items, or 15-20 days for out-of-stock items, depending on quantity.
Q: Do you provide samples? Are they free or extra?
A: Yes, we offer free samples but the customer pays for freight.
Q: What are your payment terms?
A: For orders ≤$1000, 100% payment in advance. For orders >$1000, 30% T/T deposit with balance before shipment.
