Custom Cemented Tungsten Carbide Alloy Triangle Slitting Blade with YG8/YG9C/YG11C Grade for Industrial Machine Knife

Large Image : Custom Cemented Tungsten Carbide Alloy Triangle Slitting Blade with YG8/YG9C/YG11C Grade for Industrial Machine Knife

Product Details: Payment & Shipping Terms:

Minimum Order Quantity:	5 pieces
Price:	CN¥35.69/pieces 5-199 pieces

Contact Now

Custom Cemented Tungsten Carbide Alloy Triangle Slitting Blade with YG8/YG9C/YG11C Grade for Industrial Machine Knife

Description

Place Of Origin:	Sichuan, China	Warranty:	6 Months
Video Outgoing-inspection:	Not Available	Machinery Test Report:	Provided
Core Components:	Gear	Type:	Cutting Blade
Brand Name:	Kedel	Product Name:	Tungsten Carbide Chemical Fiber Blade
Material:	100% Pure Tungsten Carbide Powder	Advantage:	High Wear Resistance
Size:	Customer Required	Packing:	Plastic Box
Application Machine:	Chemical Fiber Slitting Machine	Shape:	Triangle
Grade:	YG8/YG9C/YG11C	MOQ:	5 PIECES
Color:	Black
Highlight:	Custom Triangle Single Hole Positioning Knife , Cemented Tungsten Carbide Positioning Knife , Custom Fabric Film Slitting Knife

Custom Cemented Tungsten Carbide Alloy Triangle Single Hole Positioning Blade Fabric Film Slitting Industrial Machine Knife

Material Specifications

Grade	Composition (% in weight)	Physical Properties				Grain size (μm)
	WC	Ni	Ti	TaC	Density g/cm³ (±0.1)	Hardness HRA (±0.5)	TRS Mpa (min)	Porosity A/B/C
KD115/YG6X	93.5	6.0	-	0.5	14.90	93.0	2700	A02/B00/C00	0.6-0.8
KD335/YG10X	89.0	10.5	-	0.5	14.40	91.8	3800	A02/B00/C00	0.6-0.8
KG6/YG6	94.0	6.0	-	-	14.90	90.5	2500	A02/B00/C00	1.2-1.6
KG8/YG8	92.0	8.0	-	-	14.75	90.0	3200	A02/B00/C00	1.2-1.6
KG9/YG9	91.0	9.0	-	-	14.60	89.0	3200	A02/B00/C00	1.2-1.6
KG9C/YG9C	91.0	9.0	-	-	14.60	88.0	3200	A02/B00/C00	1.6-2.4
KG10/KG10	90.0	10.0	-	-	14.50	88.5	3200	A02/B00/C00	1.2-1.6
KG11/YG11	89.0	11.0	-	-	14.35	89.0	3200	A02/B00/C00	1.2-1.6
KG11C/YG11C	89.0	11.0	-	-	14.40	87.5	3000	A02/B00/C00	1.6-2.4
KG13/YG13	87.0	13.0	-	-	14.20	88.7	3500	A02/B00/C00	1.2-1.6
KG13C/YG13C	87.0	13.0	-	-	14.20	87.0	3500	A02/B00/C00	1.6-2.4
KG15/YG15	85.0	15.0	-	-	14.10	87.5	3500	A02/B00/C00	1.2-1.6
KG15C/YG15C	85.0	15.0	-	-	14.00	86.5	3500	A02/B00/C00	1.6-2.4
KD118/YG8X	91.5	8.5	-	-	14.50	93.6	3800	A02/B00/C00	0.4-0.6
KD338/YG12X	88.0	12.0	-	-	14.10	92.8	2200	A02/B00/C00	0.4-0.6
KD25/P25	77.4	8.5	6.5	6.0	12.60	91.8	2200	A02/B00/C00	1.0-1.6
KD35/P35	69.2	10.5	5.2	13.8	12.70	91.1	2500	A02/B00/C00	1.0-1.6
KD10/M10	83.4	7.0	4.5	4.0	13.25	93.0	2000	A02/B00/C00	0.8-1.2
KD20/M20	79.0	8.0	7.4	3.8	12.33	92.1	2200	A02/B00/C00	0.8-1.2

NOTE: Customization available per customer drawing or actual sample

Standard Sizes and Applications

No.	Dimensions (mm)	Applicable Cutting Materials
1	74.515.50.884	Blades used in the chemical fiber clothing industry. Suitable for cutting kraft paper, plastic film, wrapping film, bubble film, PE film, PP film, breathable membrane, etc.
2	90100.9
3	95190.884
4	115.318.540.84
5	117.515.50.9
6	118191.5
7	13518.51.4
8	13519.051.4
9	135.519.051.4
10	140190.884
11	140191.4
12	170190.884
13	19318.90.884

FAQ

Q: How to obtain an accurate quotation from Kedel Tools?

A: Please provide us with specific material requirements, precise dimensions, and drawings that include tolerances and quantities for different models. This will allow us to provide you with a more accurate quote.

Q: How does our company ensure the quality of its products?

A: We have inspection processes from raw material production, to finished product grinding, to cleaning and packaging. Each process also has sampling inspection. If the product in the previous process is not qualified, it will never enter the second process. Ensure the quality of the finished product.

Q: How long does a typical production cycle take?

A: For products that are often in stock, they can be shipped directly. For customized products, the specific judgment is based on the difficulty level of product processing. Normally, non-standard products require 20-25 days for production.

Q: What is our company’s payment method?

A: We accept wire transfers, L/C, ALIPAY, WEST UNION, PAYPAL, 100% payment is required for standard products before shipment, 50% for non-standard products before production, and 50% before shipment.
