Product Details:
|
Material: | Cemented Alloy | Grade: | YG10X |
---|---|---|---|
Surface: | Polished | Size: | 6mm*3000mm |
Origin Of Place: | Sichuan, China | MOQ: | 10 PCS |
Product Craft: | HIP Sintered | Service: | OEM,ODM |
Highlight: | Tungsten Carbide Rods 300mm,Sintered Finishing tungsten carbide rod blanks,Tungsten Carbide Rods 330mm |
tungsten carbide rods:
1. Grade: 10% cobalt and 12% cobalt recommend
2. Size: Diameter 4--30mm available
3. Certification: ISO9001,
4. Mirror polished to h6 available
5. Metric and Inch dimensions available
6. Standard length: 330mm/310mm and can cut into different length as per requirments
cheap price tungsten carbide solid round rod Features
1. Excellent quality and reasonable price
2. 100% raw material
3. Good abrasion, heat and corrosion resistance
4. Various size and shape, grade
Production Process:
Below are the production processes of tungsten carbide rods, to ensure high quality, we assureed our customers that:
1. All materials are tested in terms of density, hardness and T.R.S before use.
2. Every piece of product goes through in-process and final inspection.
3. Every batch of product can be traced.
tungsten carbide rods
Grade | ISO grade |
Grain size (um) |
Binder |
density (g/cm³) |
Hardness (HV30) |
Hardness (HRA) |
T.R.S (N/m㎡) |
KD10F | K05-K10 | 0.4 | 6 | 14.9 | 1950 | 93.0 | 2800 |
KD10M | K05-K10 | 1.2 | 6 | 14.8 | 1510 | 91.0 | 2600 |
KD15 | K10-K20 | 0.8 | 8 | 14.6 | 1610 | 92.0 | 3000 |
KD20(YG10X) | K20-K30 | 0.8 | 10 | 14.4 | 1610 | 92.0 | 3800 |
KD20F(YL10.2) | K20-K30 | 0.6 | 10 | 14.5 | 1570 | 91.5 | 3600 |
KD25UF | K30-K40 | 0.4 | 12 | 14.2 | 1610 | 92.0 | 4000 |
KD30M | K30-K40 | 1.5 | 15 | 14.2 | 1150 | 87.5 | 3200 |
FAQ
