Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment

Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment
Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment

Large Image :  Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment

Product Details:
Place of Origin: Sichuan, China
Brand Name: Kedel
Model Number: YG13
Payment & Shipping Terms:
Minimum Order Quantity: 5
Price: $6-21
Contact Now

Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment

Description
Material: 100% Pure Tungsten Carbide Powder Grade: YG8/YG9C/YG11C
Shape: Cylindrical Surface: Glossy
Color: Black Density: 14.90 G/cm³
Hardness: 93.0 HRA TRS: 2700 Mpa
Porosity: A02/B00/C00 Grain Size: 0.6-0.8 μm
Outer Diameter: 16.41 Mm Inner Diameter: 14.05 Mm
Pore Diameter: 12.70 Mm Length: 25.40 Mm
Step Length: 1.00 Mm
Highlight:

100% Pure Tungsten Carbide Sleeve

,

Customized Size Carbide Nozzle Sleeve

,

Spiral Thread Design Tungsten Carbide Bushing

Customized High Wear Resistant Tungsten Carbide Spiral Thread Nozzle Sleeves Bushings
YG8 YG9C for PDC Drilling Oil Equipment
Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment 0 Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment 1
Product Parameters
Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment 2 Customized High Wear Resistant Tungsten Carbide Sleeve with Spiral Thread Design for PDC Drilling Equipment 3
Grade Composition(% in weight) Physical Properties Grain size(μm)

WC Ni Ti TaC Density g/cm³(±0.1) Hardness HRA(±0.5) TRS Mpa(min) Porosity A/B/C
KD115/YG6X 93.5 6.0 - 0.5 14.90 93.0 2700 A02/B00/C00 0.6-0.8
KD335/YG10X 89.0 10.5 - 0.5 14.40 91.8 3800 A02/B00/C00 0.6-0.8
KG6/YG6 94.0 6.0 - - 14.90 90.5 2500 A02/B00/C00 1.2-1.6
KG8/YG8 92.0 8.0 - - 14.75 90.0 3200 A02/B00/C00 1.2-1.6
KG9/YG9 91.0 9.0 - - 14.60 89.0 3200 A02/B00/C00 1.2-1.6
KG9C/YG9C 91.0 9.0 - - 14.60 88.0 3200 A02/B00/C00 1.6-2.4
KG10/KG10 90.0 10.0 - - 14.50 88.5 3200 A02/B00/C00 1.2-1.6
KG11/YG11 89.0 11.0 - - 14.35 89.0 3200 A02/B00/C00 1.2-1.6
KG11C/YG11C 89.0 11.0 - - 14.40 87.5 3000 A02/B00/C00 1.6-2.4
KG13/YG13 87.0 13.0 - - 14.20 88.7 3500 A02/B00/C00 1.2-1.6
KG13C/YG13C 87.0 13.0 - - 14.10 87.0 3500 A02/B00/C00 1.6-2.4
KG15/YG15 85.0 15.0 - - 14.00 87.5 3500 A02/B00/C00 1.2-1.6
KG15C/YG15C 85.0 15.0 - - 14.50 86.5 3500 A02/B00/C00 1.6-2.4
KD118/YG8X 91.5 8.5 - - 14.10 93.6 3800 A02/B00/C00 0.4-0.6
KD338/YG12X 88.0 12.0 - - 12.60 92.8 2200 A02/B00/C00 0.4-0.6
KD25/P25 77.4 8.5 6.5 6.0 12.70 91.8 2200 A02/B00/C00 1.0-1.6
KD35/P35 69.2 10.5 5.2 13.8 13.25 91.1 2500 A02/B00/C00 1.0-1.6
KD10/M10 83.4 7.0 4.5 4.0 12.33 93.0 2000 A02/B00/C00 0.8-1.2
KD20/M20 79.0 8.0 7.4 3.8 12.33 92.1 2200 A02/B00/C00 0.8-1.2
NOTE: Customization available per customer drawing or actual sample
Specifications
Specification OD(D:mm) ID(D1:mm) Pore(d:mm) Length(L;mm) Step length(L1:mm)
01 16.41 14.05 12.70 25.40 1.00
02 16.41 14.05 12.70 31.75 1.00
03 22.04 18.86 15.75 31.75 3.18
04 22.04 18.86 15.75 50.80 3.18
05 16.00 13.90 10.31 76.20 3.18
06 22.00 18.88 14.30 25.40 3.18
07 24.00 21.00 16.00 75.00 3.00
08 22.90 21.00 15.00 75.00 3.00
09 19.50 16.90 12.70 50.00 4.00
10 36.80 32.80 26.00 55.00 4.00
