Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters

Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters
Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters

Large Image :  Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters

Product Details:
Place of Origin: Sichuan, China
Brand Name: Kedel
Model Number: YG8
Payment & Shipping Terms:
Minimum Order Quantity: 5
Price: $2-12
Contact Now

Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters

Description
Overall Length: 1.5 In Material Composition: Tungsten Carbide And Cobalt
Alloy Grades: YG8, YG6, YG6X, YG9C, YG11C, YG13C Density Range: 12.00-14.90 G/cm³
Hardness Range: 86.5-93.6 HRA TRS Range: 2000-3800 Mpa
Grain Size: 0.4-2.4 μm Porosity Grade: A02/B00/C00
Diameter Range: 1.5-32 Mm Diameter Tolerance: ±0.5_+0.4 Mm (Unground), H6 (Fine Ground)
Length Tolerance: +2_+6 Mm (Unground), ±2_+6 Mm (Fine Ground) Shape: Cylindrical
Surface Finish: Glossy Cut Type: Single Cut
Engine Type: Electric
Highlight:

YG9C Tungsten Carbide Rod

,

YG11C Cemented Carbide Rod

,

YG13C Hard Alloy Rod

Customized Tungsten Carbide Alloy Rod
High hardness and wear resistant tungsten carbide alloy rods for manufacturing drill bits and milling cutters.
Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters 0 Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters 1
Product Parameters
Customized YG9C YG11C YG13C Tungsten Carbide Rod with High Hardness and Wear Resistance for Drill Bits and Milling Cutters 2
Grade Composition (% in weight) Physical Properties Grain size (μm)
WC Ni Ti TaC Density g/cm³ (±0.1) Hardness HRA (±0.5) TRS Mpa (min) Porosity A/B/C
KD115/YG6X93.56.0-0.514.9093.02700A02/B00/C000.6-0.8
KD335/YG10X89.010.5-0.514.4091.83800A02/B00/C000.6-0.8
KG6/YG694.06.0--14.9090.52500A02/B00/C001.2-1.6
KG8/YG892.08.0--14.7590.03200A02/B00/C001.2-1.6
KG9/YG991.09.0--14.6089.03200A02/B00/C001.2-1.6
KG9C/YG9C91.09.0--14.6088.03200A02/B00/C001.6-2.4
KG10/KG1090.010.0--14.5088.53200A02/B00/C001.2-1.6
KG11/YG1189.011.0--14.3589.03200A02/B00/C001.2-1.6
KG11C/YG11C89.011.0--14.4087.53000A02/B00/C001.6-2.4
KG13/YG1387.013.0--14.2088.73500A02/B00/C001.2-1.6
KG13C/YG13C87.013.0--14.2087.03500A02/B00/C001.6-2.4
KG15/YG1585.015.0--14.1087.53500A02/B00/C001.2-1.6
KG15C/YG15C85.015.0--14.0086.53500A02/B00/C001.6-2.4
KD118/YG8X91.58.5--14.5093.63800A02/B00/C000.4-0.6
KD338/YG12X88.012.0--14.1092.82200A02/B00/C000.4-0.6
KD25/P2577.48.56.56.012.6091.82200A02/B00/C001.0-1.6
KD35/P3569.210.55.213.812.7091.12500A02/B00/C001.0-1.6
KD10/M1083.47.04.54.013.2593.02000A02/B00/C000.8-1.2
KD20/M2079.08.07.43.812.3392.12200A02/B00/C000.8-1.2
NOTE: Customization available per customer drawing or actual sample
Unground Rods Specifications
D (mm) Tolerance L (mm) Tolerance
1.5-32±0.5/+0.4310/330+2/+6
Fine Grounded Rods Specifications
D (mm) Tolerance L (mm) Tolerance
1.5-32h6310/330±2/+6
