Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines

Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines
Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines

Large Image :  Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines

Product Details:
Place of Origin: China
Payment & Shipping Terms:
Minimum Order Quantity: 5
Price: $0.50-2
Contact Now

Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines

Description
Material: 100% Tungsten Carbide Alloy Specification: YG8, YG6, YG6X, YG9C, YG11C, YG13C
Surface Finish: Glossy Power Source: Electric
Shape: Cylindrical Color: Black Alloy
Density Range: 12.00-14.90 G/cm³ Hardness Range: 86.5-93.6 HRA
TRS Range: 2000-3800 Mpa Porosity Grade: A02/B00/C00
Grain Size: 0.4-2.4 μm Ball Diameter: 15.88-57.15 Mm
Seat Height: 12.7 Mm Seat OD: 20.14-78.03 Mm
Seat ID: 11.68-45.47 Mm
Highlight:

Customized Size Tungsten Carbide Ball Valve

,

High Wear Resistance Tungsten Carbide Valve

,

100% Tungsten Carbide Material Ball Valve

Customized Cemented Tungsten Carbide Alloy Ball Valve

High-performance ball valve designed for long-distance pipelines in paper making, water conservancy, and power industries.

Product Overview
Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 0 Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 1
Technical Specifications
Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 2
Grade Composition (% in weight) WC Ni Ti TaC Density g/cm³ (±0.1) Hardness HRA (±0.5) TRS Mpa (min) Porosity Grain size (μm)
KD115/YG6X 93.5 6.0 - 0.5 14.90 93.0 2700 A02/B00/C00 0.6-0.8
NOTE: Customization available per customer drawing or actual sample
API Specifications
API Type/Symbol V11-106 V11-125 V11-150 V11-175 V11-200 V11-225 V11-250 V11-375
Ball-D(mm) 5/8"15.88 3/4"19.05 15/16"23.83 1-1/8"28.58 1-1/8"28.58 1-3/8"34.93 12/3"42.88 2-1/4"57.15
Product Images
Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 3
Why Choose Our Products
Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 4
Company Profile
Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 5
Exhibition Highlights
Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 6 Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 7 Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 8 Customized Size High Wear Resistance Tungsten Carbide Ball Valve with 100% Tungsten Carbide Material for Long-Distance Pipelines 9

In our journey at Kedel Technology Co., Ltd. in Chengdu, every encounter with you is our honor. We are well aware that being able to stop here among the many choices is our greatest support and recognition. Your satisfaction is our relentless pursuit, and every positive review and repurchase is the driving force that inspires us to keep moving forward.
