Customized High Strength Impact Resistant Tungsten Carbide Strip and Plate with YG8 YG6 YG6X YG9C YG11C YG13C Alloy Specification

Large Image : Customized High Strength Impact Resistant Tungsten Carbide Strip and Plate with YG8 YG6 YG6X YG9C YG11C YG13C Alloy Specification

Product Details:

Place of Origin:	Sichuan, China
Brand Name:	Kedel
Model Number:	YG13C

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	$3-15

Contact Now

Customized High Strength Impact Resistant Tungsten Carbide Strip and Plate with YG8 YG6 YG6X YG9C YG11C YG13C Alloy Specification

Description

Material Composition:	Tungsten Carbide And Cobalt	Alloy Specification:	YG8, YG6, YG6X, YG9C, YG11C, YG13C
Surface Finish:	Glossy	Shape:	Strip
Density Range:	12.00-14.90 G/cm³	Hardness Range:	86.5-93.6 HRA
TRS Range:	2000-3800 Mpa	Porosity Grade:	A02/B00/C00
Grain Size:	0.4-2.4 μm	Diameter Tolerance:	±0.5_+0.4 Mm (Unground), H6 (Fine Ground)
Length Tolerance:	+2_+6 Mm (Unground), ±2_+6 Mm (Fine Ground)	Diameter Range:	1.5-32 Mm
Length Range:	310-330 Mm	WC Content:	69.2-94.0%
Ni Content:	6.0-15.0%
Highlight:	YG8 YG6 YG6X YG9C YG11C YG13C Tungsten Carbide Strip , High Strength Tungsten Carbide Plate , Impact Resistant Hard Alloy Strip

Customized High-Quality Tungsten Carbide Alloy Strip

Premium tungsten carbide alloy strips engineered for high strength and impact resistance, ideal for manufacturing fastener molds.

Product Specifications

Technical Parameters

Grade	Composition (% in weight)	WC	Ni	Ti	TaC	Density g/cm³ (±0.1)	Hardness HRA (±0.5)	TRS Mpa (min)	Porosity A/B/C
KD115/YG6X	93.5	6.0	-	0.5	14.90	93.0	2700	A02/B00/C00	0.6-0.8
KD335/YG10X	89.0	10.5	-	0.5	14.40	91.8	3800	A02/B00/C00	0.6-0.8
KG6/YG6	94.0	6.0	-	-	14.90	90.5	2500	A02/B00/C00	1.2-1.6
KG8/YG8	92.0	8.0	-	-	14.75	90.0	3200	A02/B00/C00	1.2-1.6
KG9/YG9	91.0	9.0	-	-	14.60	89.0	3200	A02/B00/C00	1.2-1.6
KG9C/YG9C	91.0	9.0	-	-	14.60	88.0	3200	A02/B00/C00	1.6-2.4
KG10/KG10	90.0	10.0	-	-	14.50	88.5	3200	A02/B00/C00	1.2-1.6
KG11/YG11	89.0	11.0	-	-	14.35	89.0	3200	A02/B00/C00	1.2-1.6
KG11C/YG11C	89.0	11.0	-	-	14.40	87.5	3000	A02/B00/C00	1.6-2.4
KG13/YG13	87.0	13.0	-	-	14.20	88.7	3500	A02/B00/C00	1.2-1.6
KG13C/YG13C	87.0	13.0	-	-	14.20	87.0	3500	A02/B00/C00	1.6-2.4
KG15/YG15	85.0	15.0	-	-	14.10	87.5	3500	A02/B00/C00	1.2-1.6
KG15C/YG15C	85.0	15.0	-	-	14.00	86.5	3500	A02/B00/C00	1.6-2.4
KD118/YG8X	91.5	8.5	-	-	14.50	93.6	3800	A02/B00/C00	0.4-0.6
KD338/YG12X	88.0	12.0	-	-	14.10	92.8	2200	A02/B00/C00	0.4-0.6
KD25/P25	77.4	8.5	6.5	6.0	12.60	91.8	2200	A02/B00/C00	1.0-1.6
KD35/P35	69.2	10.5	5.2	13.8	12.70	91.1	2500	A02/B00/C00	1.0-1.6
KD10/M10	83.4	7.0	4.5	4.0	13.25	93.0	2000	A02/B00/C00	0.8-1.2
KD20/M20	79.0	8.0	7.4	3.8	12.33	92.1	2200	A02/B00/C00	0.8-1.2

NOTE: Customization available per customer drawing or actual sample

Unground Rods Specifications

D (mm)	Tolerance	L (mm)	Tolerance
1.5-32	±0.5/+0.4	310/330	+2/+6

Fine Grounded Rods Specifications

D (mm)	Tolerance	L (mm)	Tolerance
1.5-32	h6	310/330	±2/+6
